Leviton pigtail 50PSC-M03
پيگتيل مالتي مود لويتون با پارت نامبر 50PSC-M03 يک پيگتيل SC به طول 3 متر مي باشد .
Fiber Cabling System
Beige(MM Connector);Aqua (LOMM Connector);Blue (SM/UPC Connector);Green (SM/APC Connector)
IDW Country of Origin
Leviton® 50PSC-M03 PTAIL OM2 SC 3M
All Connectors Have Precision Pre-radiused Zirconia Ferrules, Corning Glass Fiber or Equivalent, Made in China
Fiber Optic Patch Cord
Pigtail, 50/125UM , .9MM Tight Byffer Cable, SC Connector, Multimode, 3 Meter Length
Leviton single-mode and multi-mode economy series pigtails are designed to support both fusion and mechanical splicing for fiber cabling systems. The pigtails are available separately or in kits for ease of installation and ordering.
Single-mode and multimode fiber optic pigtails shall be available in three meter lengths made for OFNR fiber optic cable , and be compliant with ANSI/TIA_568_C.3 and ANSI/TIA_598_C.single mode pigtails shall come in ST,SC and LC connector styles and offer UPS and APC polish types .multi-mode pigtails shall come in ST,SC,LC connector styles and offer OM1,OM2,OM3 and OM4 core styles.
- Available in ST,SC and LC connectors
- All assemblies are 100% optically tested
- All pigtails are serialized for traceability
- Support equipment for complete network solutions
- Pigtails in kit are individually colored to easily match color_ coded(900 or250µm) fiber cable that will be spliced
- Quick-turn service for fast delivery
DESIGN CONSIDERATIONS :
• Easy-strip 900 µm buffered fiber • Fiber available: OM1, OM2, OM3, OM4, and OS2 • Splice sleeves, holders, and trays available from Leviton • 12-fiber color-coded pigtail kits per ANSI/TIA-598-C
STANDARDS COMPLIANCE :
GR 1435; General Requirements for Multi-Fiber Optical Connectors ANSI/TIA-568-C.3; Optical Fiber Cabling Components Standard Kits are color compliant per ANSI/TIA-598-C.
PHYSICAL SPECIFICATIONS :
Dimensions: Three meters long Materials: 900 µm buffered fiber Colors (kit): Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Purple, Rose, and Aqua
COUNTRY OF ORIGIN : China
WARRANTY INFORMATION : For a copy of Leviton product warranties, visit www.Leviton.com/warranty
